Digital Bevel Protractor

GemRed Universal Digital Bevel Protractor

Model: 1-UP100 New Arrivals Angle Tools High-Precision Instrument

Key Features:

  • 1. Measuring at power-on with ABS mode, no calibration required.
  • 2. High-quality material with stainless Steel throughout.
  • 3. High-precision machining process ensures product quality.
  • 4. Easy to read with the large HD-LCD screen display.
  • 5. Numbers invert for Working Overhead.
  • 6. Switch to a supplementary angle.
  • 7. It features a fine adjustment knob for exact settings.
  • 8. Lock measuring data at any angle with a good locking function.

Share it:


Resolution 0.01°
Place of Origin Guangxi, China
Manufacturer  GemRed
Accuracy ±0.07°
Measuring range  0° – 360° ; 2X180°; 4X90°
Weight 340g
Size 137*75*33mm
Battery CR2032
Display Type  LCD
Battery DC 3V CR2032
Anti-interference level EMC-2 level
Working température 0°C-+40°C
Working humidity ≤ 85%RH
Protection class IP54


A digital bevel protractor is a versatile measuring tool designed to accurately measure and transfer angles in various applications, including woodworking, metalworking, construction, and engineering. It combines the functionality of a traditional bevel protractor with the precision and convenience of a digital display.

Key features and benefits of a digital bevel protractor:

Digital readout: The protractor features a digital display that provides precise and easy-to-read angle measurements in degrees, eliminating the need for manual calculations or estimations.

Adjustable arms: The protractor typically has two adjustable arms that can be positioned and locked at any angle. This allows for accurate measurement of angles between surfaces, edges, or objects.

Hold function: Many digital bevel protractors have a hold function that allows you to freeze the displayed angle measurement, even when the arms are moved. This is useful for transferring angles from one surface to another.

Backlit display: Some models come with a backlit display, making it easier to read measurements in low-light conditions.

Multiple measurement modes: Some digital bevel protractors offer multiple measurement modes, such as absolute angle measurement (measuring the angle from a fixed reference point) and relative angle measurement (measuring the angle change from a starting position).

Compact and portable: Digital bevel protractors are generally compact and lightweight, making them easy to carry and use in various job site or workshop environments.

Durable construction: These protractors are typically made of durable materials, such as stainless steel or aluminum, to withstand the rigors of everyday use.

Professional Digital Bevel Protractor

High Precision Measurement: Provides highly accurate angle measurements with a typical accuracy range of ±0.1 degrees, ideal for precision work.

Large Digital Display: Equipped with an easy-to-read, backlit LCD screen that displays measurements in degrees, percent, or mm/m, facilitating clear readings even in low-light conditions.

Durable Construction: Crafted from industrial-grade stainless steel, ensuring long-lasting durability and resistance to corrosion and wear.

360-Degree Range: Capable of measuring full 360-degree angles, allowing for comprehensive angle measurement in various applications.

Magnetic Base: Features a strong magnetic base for stable attachment to metal surfaces, enhancing ease of use and accuracy in measurements.

Rechargeable Battery: Comes with a built-in rechargeable lithium-ion battery and a USB charging cable, offering extended use and convenience.

User-Friendly Interface: Simple button operation for easy calibration, angle holding, and switching between measurement modes.

Versatile Use: Ideal for a wide range of applications including woodworking, welding, assembly, and fabrication.

Compact and Portable: Ergonomically designed for comfortable handling and ease of transport, making it suitable for both field and workshop use.

Data Output Capability: Equipped with a data output function for connecting to computers or printers for record-keeping and detailed analysis (optional feature).

Package Contents:

Digital Bevel Protractor

Protective Carrying Case

USB Charging Cable

User Manual

Calibration Certificate


Measurement Range: 0 to 360 degrees

Resolution: 0.1 degrees

Accuracy: ±0.1 degrees

Dimensions: [provide specific dimensions]

Weight: [provide weight]
